FLUKE 62 MAX+ Infrared Thermometer
QUICK SPECS
PRODUCT TECHNICAL SPECIFICATIONS
REFERENCE DOCUMENTS
Datasheets, manuals, catalogues, certificates and other available product documents.
Overview
FLUKE 62 MAX+ is a handheld non-contact infrared thermometer with a -30°C to +650°C range, Dual Laser, 12:1 distance-to-spot ratio, and IP54 protection.
FLUKE 62 MAX+ Overview
FLUKE 62 MAX+ is a handheld non-contact infrared thermometer for industrial inspection and maintenance. It enables surface-temperature measurement without direct contact with the equipment being checked.
Key functions and features
- Temperature measurement range from -30°C to +650°C.
- Dual Laser for measurement-area targeting and a 12:1 distance-to-spot ratio.
- Adjustable emissivity from 0.10 to 1.00.
- MIN/MAX/AVG/DIF functions, HI/LO alarm, and backlit display.
- Selectable °C/°F units and operation from one AA battery.
- IP54 protection rating and 3 m drop test.
Applications
- Surface-temperature checks on electrical panels, MCCs, circuit breakers, contactors, terminals, busbars, fuses, and cable connections.
- Checks on motor housings, bearing areas, couplings, gearboxes, and areas showing abnormal heating.
- Checks on pipes, ducts, vents, coils, compressors, refrigeration, and HVAC systems.
- Surface checks on tanks, piping, steam lines, thermal systems, and production equipment.
Selection and use guidance
The instrument is suited to periodic surface-temperature inspections in factories, M&E facilities, and MRO maintenance work. For trend monitoring, measure the same location repeatedly and compare readings between inspections. Use the Dual Laser to target the measurement area, and consider the 12:1 distance-to-spot ratio when selecting the measuring distance.
Technical and safety notes
FLUKE 62 MAX+ measures surface temperature by infrared and does not measure internal object temperature. Set emissivity appropriately for the measured surface. The laser is IEC 60825-1 Class 2; follow laser safety instructions during use. Non-contact measurement is useful for hot, moving, or difficult-to-reach surfaces, but it does not eliminate all safety risks.
Applications & selection
Application suitability must be checked against technical data, operating conditions and installation requirements.
Verify technical ratings, environment, load, mounting, standards and required accessories before selection.
Documents & guides
No verified manufacturer document is linked yet; add datasheet/catalogue/manual before approval.
